Veryon AIRE: |
Reference [1] contains relevant information to answer how to remove the starter. Here are the steps from that reference:
Procedure for Removing the Starter Ring Gear Support Assembly:
1. Remove the starter ring gear support assembly (32, figure 7-5) from the crankshaft propeller flange by tapping lightly on the rear face of the assembly.
2. The alternator or generator drive belt will be removed with this unit.
|
Veryon AIRE: |
Based on the provided references, the relevant information to answer "What is the torque spec for the 'cylinder' base nuts?" is:
[1][3] The torque spec for 3/8 cylinder hold down nuts is 300 in-lbs. The torque spec for 1/2 cylinder hold down nuts is 600 in-lbs
[2] Also mentions the same torque specs for 3/8 and 1/2 cylinder hold down nuts under reference 929.
|
Veryon AIRE: |
Based on the provided references, the key parts needed for a crankshaft inspection are:
1. Crankshaft itself
2. Magnetic particle inspection equipment
3. Cleaning solvents like trichloroethylene or environmentally friendly alternatives
4. Magnifying glass (3-7x power)
The references mention specific procedures and qualifications required for proper crankshaft inspection using magnetic particle technique. [1][2]
|
Veryon AIRE: |
The relevant references indicate that the thermostatic valve is located in the oil pressure screen housing on some engine installations. Specifically:
[1] "5-5. Thermostatic Valve and Oil Pressure Screen Housing. See figure 5-1. This unit, (5) used on some installations, is located at the same place as the oil pressure screen housing described in paragraph 5-4 and is removed in the same manner."
[2] "5-40. Thermostatic Valve and Oil Pressure Screen Housing. See figure 5-1. Assemble screen, gasket and thermostatic valve in housing."
